DriftClip® DSL


US Patent #6,612,087


DriftClip® DSL is available to accommodate vertical deflection and lateral drift requirements at head of wall. Step Bushings pre-installed in vertical slots allow up to 2” vertical deflection (1” up and down). Horizontal slots accommodate 2” lateral drift (1” left and right-in-plane), with Step Bushings also preinstalled through the manufacturing process.  Load tables are provided for attachment to stud. If more than 2” lateral drift is required, contact TSN engineering for more information.

Value

  • Positive, load rated mechanical attachments
  • Only certified, 50ksi steel is used
  • Step Bushings pre-installed for accurate placement
  • Rated screws provided
  • Load transferred from stud web
  • Meets all building code criteria
  • Adaptable for multiple configurations

Downloads Download Technical data Tech Sheet | Download drawing file DWG | Download specification data Specs | Download BIM data BIM |
Product Information
DriftClip DSL app

Material Composition

ASTM A1003/A1003M Structural Grade 50 (340) Type H, ST50H (ST340H): 50ksi (340MPa) minimum yield strength, 65ksi (450MPa) minimum tensile strength, 97mil minimum thickness (12 gauge, 0.1017" design thickness) with ASTM A653/A653M G90 (Z275) hot dipped galvanized coating.

The attachment of DriftClip DSL to the primary structure may be made with PAFs, screws, or bolt anchors depending on the base material (steel or concrete) and the design configuration. The step bushings used for attachment to structure are designed for use with ¼" maximum diameter fasteners. Designing this connection is the responsibility of the Structural Engineer of Record, and a minimum of two fasteners must be used.

  1. Attach track to structure with required fasteners.
  2. Attach DriftClip DSL to structure with required fasteners through each Step Bushing.
  3. Attach DriftClip DSL to stud with provided #12 screws through each Step Bushing.

pdf icon Printable Installation Instructions

Order Information
Designation Qty/Box Lbs/Box Qty/Skid Lbs/Skid
DSL362/400 50 36 2,250 1,620
DSL362/400-CA 50 36 2,250 1,620
DSL600 50 60 2,250 2,700
DSL600-CA 50 60 2,250 2,700
DSL800 25 40 1,125 1,800
DSL800-CA 25 40 1,125 1,800

Nomenclature

DriftClip DSL is classified by multiplying stud depth by 100.*

Example: 6” stud depth
Designate: DriftClip® DSL600

* Parts with the designation “-CA” on the end of the part name includes a special bushing available to allow connection to the side of the concrete slab using two ¼” concrete screw anchors.
** If more than 2” lateral drift is required, contact TSN engineering.
*** Three screws & step bushings are present in 6" sizes and higher. Refer to design requirements for required fastener quantity and placement.  TSN provides #12 screws for each bushing for connection through step bushings to stud web.

DriftClip DSL Dimensions

Allowable (Unfactored) Loads1

DriftClip® DSL, Recommended Allowable Load (lbs): F2
Stud Fastener Pattern 1
Thickness Mils (ga) Yield Strength (ksi) DSL362 w/2 #12 Screws DSL600 w/2 #12 Screws DSL600 w/3 #12 Screws DSL800 w/2 #12 Screws DSL800 w/3 #12 Screws
33 (20) 33 357 377 565 377 565
33 (20) 50 357 544 776 544 817
43 (18) 33 357 561 776 561 841
43 (18) 50 357 776 776 810 1,041
54 (16) 33 357 776 776 789 1,041
54 (16) 50 357 776 776 1,041 1,041
68 (14) 50 357 776 776 1,041 1,041
97 (12) 50 357 776 776 1,041 1,041
Max Allowable Clip Load 357 776 1,041



DriftClip® DSL, Recommended Allowable Load (lbs): F2
Stud Fastener Pattern 2
Thickness Mils (ga) Yield Strength (ksi) DSL362 w/2 #12 Screws DSL600 w/2 #12 Screws DSL600 w/3 #12 Screws DSL800 w/2 #12 Screws DSL800 w/3 #12 Screws
33 (20) 33 129 377 418 377 565
33 (20) 50 129 418 418 544 817
43 (18) 33 129 418 418 560 841
43 (18) 50 129 418 418 810 1,041
54 (16) 33 129 418 418 789 1,041
54 (16) 50 129 418 418 1,041 1,041
68 (14) 50 129 418 418 1,041 1,041
97 (12) 50 129 418 418 1,041 1,041
Max Allowable Clip Load 129 418 1,041

Notes:

  • Design loads are for attachment of DriftClip DSL to stud only. Load tables reflect horizontal loads (F2).
  • Attachment to structure engineered by others.
  • Allowable loads have not been increased for wind, seismic, or other factors.
  • Two (2) #12 screws are provided with each DriftClip DSL for attachment to stud.
  • DriftClip DSL allows up to 2" of vertical deflection (1" up and 1" down), and 2" lateral drift (1" left and 1" right in plane). Deflection requirements greater than 2" lateral drift are available.
  • One row of bridging is recommended at a maximum distance of 18" from DriftClip to resist torsional effects.
  • Attachment to structure engineered by others. As a design reference, follow ICCESR- 3332 for allowable loads for screw fasteners of ¼" - 20 size with various plate thickness.

1 For LRFD Design Strengths refer to ICC-ESR-2049.

Fastener Patterns

DriftClip DSL Fastener Pattern 1
DriftClip DSL Fastener Pattern 2

Load Direction

DriftClip_DSL_Load_Direction

TSN's Product Catalogs are an essential resource for the design of cold formed steel. Developed by Engineers, the catalogs contain design data for members connectors, and fasteners.

DriftClip® DSL and the rest of TSN's Drift Connection Product Line can be found in the following Catalogs:
