GripClip®

GripClip
US Patent # 8,132,383


GripClip® is an innovative device to attach drywall and sheathing materials to a column or beam.  With its patented snap-tabs GripClip allows for the easy attachment of continuous angle along the corner of the column or beam for easier installation of drywall or sheathing.

Value

  • 'Snap tabs' accept the continuous angle for fast installation
  • Use in fire-rated and non-fire-rated assemblies
  • Manufactured from certified, 50ksi steel
  • Clip 'grips' the column or beam
  • Grips on flanges of steel columns and beams for gypsum board attachment.
  • Saves material and time vs. stud framing.
  • Corner angle snaps into place without using screws
  • Accommodates flange thickness from ¼" to 1".
  • 27 mil minimum thickness, G60 coating vs. 18 mil, G40 for competitor products.

Downloads Download Technical data Tech Sheet | Download specification data Specs | Download BIM data BIM |
Product Information

GripClip App

Material Composition

ASTM A1003 A1003/A1003M Structural Grade 33(230) Type H, ST33H (ST230H): 33ksi (230MPa) minimum yield strength, 45ksi (310MPa) minimum tensile strength, 27mil minimum thickness (22 gauge, 0.0283" design thickness) with ASTM A653/A653M G60 (Z180) hot dipped galvanized coating.

Order Information

Designation Qty/Box Lbs/Box Qty/Skid Lbs/Skid
GripClip® 48 10 2,160 450

Nomenclature

GripClip is made in one size and is designated GripClip®.

GripClip Dimensions

TSN's Product Catalogs are an essential resource for the design of cold formed steel.  Developed by Engineers, the catalogs contain design data for members, connectors, and fasteners.
GripClip® and the rest of TSN's Specialty Products can be found in the following Catalogs:
