SigmaStud®

SigmaStud

US Patent Pending


SigmaStud® is a breakthrough in the load-bearing steel stud industry, producing significant increases in load capacity when compared with conventional "C" Shaped metal studs. SigmaStud's unique configuration provides installation and design advantages which create efficiencies no other light steel framing (LSF)  studs can provide for load bearing walls. Each bend made to a flat LSF element increases load capacity over a standard stud section with the same material thickness. The return lips present in SigmaStud also increase capacity, delivering the most efficient LSF load-bearing stud member available. TSN’s 600SG™ and 800SG™ product lines are for 6” and 8” walls.

Quality

  • Increases load capacity over a standard "C-shaped" stud of the same thickness, reducing overall materials needed (14ga "C-shaped" to 18ga "SG" common)
  • Re-defines previous limitations considered for utilization of steel studs in building construction
  • Larger flange width increases area for fasteners
  • Axial load capacity tables compatible with recent code changes

Value

  • Lighter weight results in shipping efficiencies and easier handling & faster connections
  • Screw size decreases with thinner material thickness of member material
  • May eliminate double studs and their attachments to each other
  • Increased load capacity produces more cost-effective options for designing load bearing walls for clients

Downloads Download Technical data Tech Sheet | Download drawing file DWG | Download specification data Specs | Download BIM data BIM |
Product Information

TSN_SG_Application

ASTM A1003/A1003M or ASTM A653/A653M, Grade 50(340), 50ksi (340MPa) minimum yield strength, 65ksi (450 MPa) minimum tensile strength, G-60 (Z180) hot-dipped galvanized coating; or equivalent.

 TSN_SigmaStud_Nomenclature_with_Examples

TSN_Large_SigmaStud_Nomenclature_Shape

5.5"-8" Depths
(bent web configuration)

TSN’s 600SG™ and 800SG™ product lines are for 6” and 8” walls.

 TSN_Small_SigmaStud_Nomenclature_Shape

3.5"-4" Depths
(flat web configuration)

SigmaStud® Product Profile
Section
(All 50 ksi)
Overall Depth Flange Width Web Flat Web Return Web Return Web Inside Return Lip 1 Return Lip 2 Inside Bend Radius Design
Thickness
Unit Weight
D B A C E N d1 d2 R t (lbs/ft)
(in) (in) (in) (in) (in) (in) (in) (in) (in) (in)
350SG200-33 3.5 2 3.5 N/A N/A N/A 0.5892 0.5 0.105 0.0346 1.078
350SG200-43 3.5 2 3.5 N/A N/A N/A 0.6102 0.5 0.105 0.0451 1.400
350SG200-54 3.5 2 3.5 N/A N/A N/A 0.6332 0.5 0.105 0.0566 1.749
350SG200-68 3.5 2 3.5 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.192
350SG200-97 3.5 2 3.5 N/A N/A N/A 0.7234 0.5 0.105 0.1017 3.092
350SG250-33 3.5 2.5 3.5 N/A N/A N/A 0.5892 0.5 0.105 0.0346 1.196
350SG250-43 3.5 2.5 3.5 N/A N/A N/A 0.6102 0.5 0.105 0.0451 1.553
350SG250-54 3.5 2.5 3.5 N/A N/A N/A 0.6332 0.5 0.105 0.0566 1.942
350SG250-68 3.5 2.5 3.5 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.435
350SG250-97 3.5 2.5 3.5 N/A N/A N/A 0.7234 0.5 0.105 0.1017 3.438
350SG350-68 3.5 3.5 3.5 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.920
350SG350-97 3.5 3.5 3.5 N/A N/A N/A 0.7234 0.5 0.105 0.1017 4.130
350SG350-118 3.5 3.5 3.5 N/A N/A N/A 0.7684 0.5 0.105 0.1242 5.005
362SG200-33 3.625 2 3.625 N/A N/A N/A 0.5892 0.5 0.105 0.0346 1.093
362SG200-43 3.625 2 3.625 N/A N/A N/A 0.6102 0.5 0.105 0.0451 1.419
362SG200-54 3.625 2 3.625 N/A N/A N/A 0.6332 0.5 0.105 0.0566 1.773
362SG200-68 3.625 2 3.625 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.222
362SG200-97 3.625 2 3.625 N/A N/A N/A 0.7234 0.5 0.105 0.1017 3.135
362SG250-33 3.625 2.5 3.625 N/A N/A N/A 0.5892 0.5 0.105 0.0346 1.210
362SG250-43 3.625 2.5 3.625 N/A N/A N/A 0.6102 0.5 0.105 0.0451 1.572
362SG250-54 3.625 2.5 3.625 N/A N/A N/A 0.6332 0.5 0.105 0.0566 1.966
362SG250-68 3.625 2.5 3.625 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.465
362SG250-97 3.625 2.5 3.625 N/A N/A N/A 0.7234 0.5 0.105 0.1017 3.481
362SG350-68 3.625 3.5 3.625 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.950
362SG350-97 3.625 3.5 3.625 N/A N/A N/A 0.7234 0.5 0.105 0.1017 4.173
362SG350-118 3.625 3.5 3.625 N/A N/A N/A 0.7684 0.5 0.105 0.1242 5.058
400SG200-33 4 2 4 N/A N/A N/A 0.5892 0.5 0.105 0.0346 1.137
400SG200-43 4 2 4 N/A N/A N/A 0.6102 0.5 0.105 0.0451 1.477
400SG200-54 4 2 4 N/A N/A N/A 0.6332 0.5 0.105 0.0566 1.846
400SG200-68 4 2 4 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.313
400SG200-97 4 2 4 N/A N/A N/A 0.7234 0.5 0.105 0.1017 3.265
400SG250-33 4 2.5 4 N/A N/A N/A 0.5892 0.5 0.105 0.0346 1.255
400SG250-43 4 2.5 4 N/A N/A N/A 0.6102 0.5 0.105 0.0451 1.630
400SG250-54 4 2.5 4 N/A N/A N/A 0.6332 0.5 0.105 0.0566 2.038
400SG250-68 4 2.5 4 N/A N/A N/A 0.6626 0.5 0.105 0.0713 2.556
400SG250-97 4 2.5 4 N/A N/A N/A 0.7234 0.5 0.105 0.1017 3.611
400SG350-68 4 3.5 4 N/A N/A N/A 0.6626 0.5 0.105 0.0713 3.041
400SG350-97 4 3.5 4 N/A N/A N/A 0.7234 0.5 0.105 0.1017 4.303
400SG350-118 4 3.5 4 N/A N/A N/A 0.7684 0.5 0.105 0.1242 5.216
550SG162-33 5.5 1.6 1 1 0.63 2.25 0.5000 0 0.105 0.0346 1.232
550SG162-43 5.5 1.6 1 1 0.63 2.25 0.5000 0 0.105 0.0451 1.598
550SG200-33 5.5 2 1 1 0.63 2.25 0.5892 0.5 0.105 0.0346 1.438
550SG200-43 5.5 2 1 1 0.63 2.25 0.6102 0.5 0.105 0.0451 1.869
550SG200-54 5.5 2 1 1 0.63 2.25 0.6332 0.5 0.105 0.0566 2.338
550SG200-68 5.5 2 1 1 0.63 2.25 0.6626 0.5 0.105 0.0713 2.933
550SG200-97 5.5 2 1 1 0.63 2.25 0.7234 0.5 0.105 0.1017 4.147
550SG250-33 5.5 2.5 1 1 0.63 2.25 0.5892 0.5 0.105 0.0346 1.556
550SG250-43 5.5 2.5 1 1 0.63 2.25 0.6102 0.5 0.105 0.0451 2.023
550SG250-54 5.5 2.5 1 1 0.63 2.25 0.6332 0.5 0.105 0.0566 2.531
550SG250-68 5.5 2.5 1 1 0.63 2.25 0.6626 0.5 0.105 0.0713 3.176
550SG250-97 5.5 2.5 1 1 0.63 2.25 0.7234 0.5 0.105 0.1017 4.493
550SG300-43 5.5 3 1 1 0.63 2.25 0.6102 0.5 0.105 0.0451 2.176
550SG300-54 5.5 3 1 1 0.63 2.25 0.6332 0.5 0.105 0.0566 2.723
550SG300-68 5.5 3 1 1 0.63 2.25 0.6626 0.5 0.105 0.0713 3.418
550SG300-97 5.5 3 1 1 0.63 2.25 0.7234 0.5 0.105 0.1017 4.839
550SG300-118 5.5 3 1 1 0.63 2.25 0.7684 0.5 0.105 0.1242 5.867
600SG162-33 6 1.6 1.25 1 0.63 2.25 0.5000 0 0.105 0.0346 1.291
600SG162-43 6 1.6 1.25 1 0.63 2.25 0.5000 0 0.105 0.0451 1.674
600SG200-33 6 2 1.25 1 0.63 2.25 0.5892 0.5 0.105 0.0346 1.497
600SG200-43 6 2 1.25 1 0.63 2.25 0.6102 0.5 0.105 0.0451 1.946
600SG200-54 6 2 1.25 1 0.63 2.25 0.6332 0.5 0.105 0.0566 2.435
600SG200-68 6 2 1.25 1 0.63 2.25 0.6626 0.5 0.105 0.0713 3.054
600SG200-97 6 2 1.25 1 0.63 2.25 0.7234 0.5 0.105 0.1017 4.320
600SG250-33 6 2.5 1.25 1 0.63 2.25 0.5892 0.5 0.105 0.0346 1.615
600SG250-43 6 2.5 1.25 1 0.63 2.25 0.6102 0.5 0.105 0.0451 2.100
600SG250-54 6 2.5 1.25 1 0.63 2.25 0.6332 0.5 0.105 0.0566 2.627
600SG250-68 6 2.5 1.25 1 0.63 2.25 0.6626 0.5 0.105 0.0713 3.297
600SG250-97 6 2.5 1.25 1 0.63 2.25 0.7234 0.5 0.105 0.1017 4.666
600SG300-43 6 3 1.25 1 0.63 2.25 0.6102 0.5 0.105 0.0451 2.253
600SG300-54 6 3 1.25 1 0.63 2.25 0.6332 0.5 0.105 0.0566 2.820
600SG300-68 6 3 1.25 1 0.63 2.25 0.6626 0.5 0.105 0.0713 3.540
600SG300-97 6 3 1.25 1 0.63 2.25 0.7234 0.5 0.105 0.1017 5.012
600SG300-118 6 3 1.25 1 0.63 2.25 0.7684 0.5 0.105 0.1242 6.078
800SG162-33 8 1.6 2.25 1 0.63 2.25 0.5000 0 0.105 0.0346 1.526
800SG162-43 8 1.6 2.25 1 0.63 2.25 0.5000 0 0.105 0.0451 1.981
800SG200-33 8 2 2.25 1 0.63 2.25 0.5892 0.5 0.105 0.0346 1.733
800SG200-43 8 2 2.25 1 0.63 2.25 0.6102 0.5 0.105 0.0451 2.253
800SG200-54 8 2 2.25 1 0.63 2.25 0.6332 0.5 0.105 0.0566 2.820
800SG200-68 8 2 2.25 1 0.63 2.25 0.6626 0.5 0.105 0.0713 3.540
800SG200-97 8 2 2.25 1 0.63 2.25 0.7234 0.5 0.105 0.1017 5.012
800SG250-33 8 2.5 2.25 1 0.63 2.25 0.5892 0.5 0.105 0.0346 1.851
800SG250-43 8 2.5 2.25 1 0.63 2.25 0.6102 0.5 0.105 0.0451 2.406
800SG250-54 8 2.5 2.25 1 0.63 2.25 0.6332 0.5 0.105 0.0566 3.012
800SG250-68 8 2.5 2.25 1 0.63 2.25 0.6626 0.5 0.105 0.0713 3.782
800SG250-97 8 2.5 2.25 1 0.63 2.25 0.7234 0.5 0.105 0.1017 5.358
800SG300-43 8 3 2.25 1 0.63 2.25 0.6102 0.5 0.105 0.0451 2.560
800SG300-54 8 3 2.25 1 0.63 2.25 0.6332 0.5 0.105 0.0566 3.205
800SG300-68 8 3 2.25 1 0.63 2.25 0.6626 0.5 0.105 0.0713 4.025
800SG300-97 8 3 2.25 1 0.63 2.25 0.7234 0.5 0.105 0.1017 5.704
800SG300-118 8 3 2.25 1 0.63 2.25 0.7684 0.5 0.105 0.1242 6.922

Table Notes:

1. Section properties and capacities are calculated in accordance with AISI S100-07 with 2010 supplement.
2. Tabulated gross properties are based on the full-unreduced cross section of the studs, away from punchouts.
3. Effective section properties incorporate the strength increase from the cold-work of forming as applicable per AISI S100-07 Sec. A7.2.
4. Net effective section properties are calculated at a cross section through the punchout.
5. Allowable moment is the lesser of Mal and Mad. Stud distortional buckling is based on an assumed kΦ = 0.
6. For deflection calculations, use the effective moment of inertia.
7. The effective moment of inertia for deflection is calculated at a stress which results in a section modulus such that the stress times the section modulus at that stress is equal to the allowable moment. AISI S100-07 Procedure I for serviceability determination has been used.
3.5-4" Depths (flat web configuration):

small_SG_Shape

5.5-8" Depths (bent web configuration):

Large_SG_Shape

SigmaStud® Section Properties
Section
(All 50 ksi)
Gross Properties Torsional Properties Effective Properties
Area Ix Sx Rx Iy Ry Jx1000 Cw Xo m Ro ß Ae(net) Ix Sx Sx(net) Mal Mal(net) Mad Va Va(net)
(in2) (in4) (in3) (in) (in4) (in) (in4) (in6) (in) (in) (in) (in2) (in4) (in3) (in3) (in-k) (in-k) (in-k) (lb) (lb)
350SG200-33 0.317 0.630 0.360 1.410 0.194 0.782 0.126 0.718 -1.975 1.178 2.549 0.400 0.201 0.615 0.310 0.283 9.295 8.479 8.570 1145 527
350SG200-43 0.411 0.810 0.463 1.404 0.249 0.779 0.279 0.929 -1.969 1.176 2.541 0.399 0.293 0.810 0.430 0.406 12.878 12.161 12.176 2141 747
350SG200-54 0.514 1.003 0.573 1.397 0.309 0.775 0.549 1.158 -1.963 1.173 2.531 0.398 0.384 1.003 0.550 0.530 16.470 15.871 16.295 3371 925
350SG200-68 0.644 1.241 0.709 1.388 0.382 0.770 1.091 1.444 -1.955 1.169 2.519 0.397 0.529 1.241 0.709 0.696 23.531 20.831 21.230 4208 900
350SG200-97 0.909 1.705 0.974 1.370 0.525 0.760 3.132 2.017 -1.938 1.160 2.492 0.395 0.756 1.705 0.974 0.958 33.387 32.831 29.168 5886 850
350SG250-33 0.351 0.734 0.419 1.445 0.329 0.967 0.140 1.206 -2.476 1.448 3.025 0.330 0.210 0.692 0.331 0.300 9.904 8.995 9.106 1145 527
350SG250-43 0.456 0.945 0.540 1.439 0.424 0.964 0.309 1.565 -2.471 1.445 3.017 0.329 0.292 0.933 0.447 0.418 13.371 12.505 13.045 2141 747
350SG250-54 0.571 1.171 0.669 1.432 0.526 0.960 0.609 1.953 -2.465 1.442 3.008 0.329 0.383 1.171 0.571 0.545 17.099 16.324 17.616 3371 925
350SG250-68 0.715 1.450 0.829 1.424 0.653 0.955 1.212 2.443 -2.457 1.439 2.996 0.328 0.519 1.450 0.748 0.728 22.400 21.809 23.676 4208 900
350SG250-97 1.010 1.999 1.142 1.406 0.904 0.946 3.483 3.431 -2.441 1.430 2.972 0.325 0.858 1.999 1.125 1.107 37.597 37.006 34.192 5886 850
350SG350-68 0.858 1.870 1.068 1.476 1.471 1.309 1.454 5.401 -3.456 1.965 3.980 0.246 0.535 1.812 0.804 0.774 24.073 23.179 26.651 4208 900
350SG350-97 1.214 2.586 1.478 1.460 2.050 1.300 4.184 7.627 -3.441 1.957 3.958 0.244 0.866 2.574 1.267 1.238 37.945 37.068 42.171 5886 850
350SG350-118 1.471 3.082 1.761 1.448 2.457 1.293 7.538 9.227 -3.430 1.951 3.941 0.243 1.173 3.082 1.670 1.644 50.000 49.221 52.725 7073 814
362SG200-33 0.321 0.683 0.377 1.459 0.196 0.782 0.128 0.759 -1.954 1.168 2.561 0.418 0.202 0.667 0.326 0.295 9.754 8.842 8.919 1102 544
362SG200-43 0.417 0.879 0.485 1.452 0.253 0.779 0.283 0.983 -1.948 1.166 2.552 0.417 0.293 0.879 0.451 0.424 13.504 12.690 12.685 2141 802
362SG200-54 0.521 1.089 0.601 1.445 0.313 0.775 0.556 1.224 -1.942 1.163 2.542 0.416 0.385 1.089 0.577 0.553 17.261 16.571 16.994 3372 994
362SG200-68 0.653 1.348 0.744 1.437 0.388 0.770 1.107 1.526 -1.934 1.159 2.530 0.415 0.532 1.348 0.744 0.728 24.678 21.799 22.265 4375 1007
362SG200-97 0.921 1.854 1.023 1.419 0.533 0.761 3.176 2.130 -1.918 1.150 2.504 0.413 0.769 1.854 1.023 1.007 35.050 34.514 30.621 6124 954
362SG250-33 0.356 0.795 0.438 1.495 0.333 0.968 0.142 1.277 -2.453 1.437 3.031 0.345 0.210 0.750 0.347 0.313 10.387 9.375 9.461 1102 544
362SG250-43 0.462 1.024 0.565 1.489 0.430 0.964 0.313 1.656 -2.447 1.435 3.023 0.344 0.293 1.011 0.468 0.435 14.012 13.038 13.565 2141 802
362SG250-54 0.578 1.269 0.700 1.482 0.533 0.961 0.617 2.066 -2.442 1.432 3.014 0.344 0.385 1.269 0.598 0.569 17.908 17.031 18.335 3372 994
362SG250-68 0.724 1.573 0.868 1.474 0.662 0.956 1.227 2.583 -2.434 1.428 3.002 0.342 0.522 1.573 0.783 0.761 23.449 22.775 24.670 4375 1007
362SG250-97 1.023 2.169 1.197 1.456 0.916 0.946 3.527 3.625 -2.418 1.420 2.977 0.340 0.870 2.169 1.178 1.161 39.389 38.814 35.835 6124 954
362SG350-68 0.867 2.023 1.116 1.528 1.491 1.311 1.469 5.715 -3.430 1.954 3.977 0.256 0.538 1.961 0.841 0.808 25.186 24.190 27.689 4375 1007
362SG350-97 1.226 2.801 1.545 1.511 2.078 1.302 4.228 8.065 -3.415 1.947 3.955 0.254 0.879 2.787 1.325 1.296 39.672 38.798 43.895 6124 954
362SG350-118 1.486 3.340 1.843 1.499 2.491 1.295 7.617 9.753 -3.404 1.941 3.938 0.253 1.189 3.340 1.746 1.721 52.284 51.518 55.170 7363 917
400SG200-33 0.334 0.859 0.429 1.603 0.204 0.782 0.133 0.895 -1.894 1.139 2.602 0.470 0.202 0.840 0.373 0.332 11.168 9.928 9.971 991 589
400SG200-43 0.434 1.107 0.553 1.597 0.263 0.778 0.294 1.157 -1.889 1.136 2.593 0.469 0.295 1.107 0.515 0.477 15.429 14.276 14.220 2141 967
400SG200-54 0.542 1.371 0.686 1.590 0.325 0.775 0.579 1.440 -1.883 1.133 2.583 0.469 0.389 1.371 0.658 0.624 19.693 18.673 19.109 3372 1201
400SG200-68 0.680 1.700 0.850 1.581 0.403 0.770 1.152 1.794 -1.875 1.129 2.571 0.468 0.540 1.700 0.850 0.825 28.202 24.708 25.444 4876 1360
400SG200-97 0.959 2.344 1.172 1.563 0.555 0.760 3.308 2.498 -1.858 1.121 2.544 0.467 0.806 2.344 1.172 1.158 40.162 34.664 35.087 6839 1299
400SG250-33 0.369 0.995 0.497 1.643 0.346 0.969 0.147 1.506 -2.386 1.407 3.055 0.390 0.211 0.941 0.397 0.351 11.873 10.514 10.530 991 589
400SG250-43 0.479 1.283 0.641 1.637 0.446 0.965 0.325 1.951 -2.381 1.404 3.046 0.389 0.294 1.268 0.534 0.489 15.981 14.635 15.133 2141 967
400SG250-54 0.599 1.591 0.796 1.630 0.554 0.962 0.640 2.432 -2.375 1.401 3.037 0.388 0.388 1.591 0.681 0.640 20.397 19.150 20.506 3372 1201
400SG250-68 0.751 1.975 0.987 1.622 0.688 0.957 1.273 3.038 -2.368 1.398 3.025 0.387 0.530 1.975 0.891 0.858 26.669 25.675 27.679 4876 1360
400SG250-97 1.061 2.730 1.365 1.604 0.953 0.948 3.658 4.255 -2.352 1.390 3.000 0.386 0.908 2.730 1.343 1.351 44.884 40.448 40.871 6839 1299
400SG350-68 0.894 2.525 1.263 1.681 1.547 1.316 1.514 6.736 -3.354 1.922 3.976 0.288 0.545 2.447 0.955 0.909 28.602 27.223 30.818 4876 1360
400SG350-97 1.265 3.503 1.751 1.664 2.158 1.306 4.360 9.488 -3.339 1.915 3.953 0.286 0.917 3.483 1.502 1.473 44.961 44.092 49.104 6839 1299
400SG350-118 1.533 4.184 2.092 1.652 2.587 1.299 7.855 11.458 -3.328 1.909 3.936 0.285 1.235 4.184 1.980 1.955 59.268 58.533 62.640 8235 1256
550SG162-33 0.362 1.522 0.554 2.051 0.096 0.514 0.144 0.864 -0.203 0.495 2.124 0.991 0.261 1.522 0.498 0.492 14.920 14.716 11.731 997 587
550SG162-43 0.469 1.963 0.714 2.045 0.122 0.510 0.318 1.097 -0.191 0.504 2.116 0.992 0.364 1.963 0.663 0.655 19.843 19.611 16.926 2141 952
550SG200-33 0.423 1.882 0.684 2.110 0.175 0.643 0.169 1.783 -0.716 0.160 2.319 0.905 0.315 1.855 0.609 0.602 18.234 18.016 14.840 997 587
550SG200-43 0.549 2.432 0.884 2.104 0.225 0.640 0.372 2.294 -0.708 0.165 2.310 0.906 0.447 2.432 0.833 0.826 24.934 24.718 21.359 2141 952
550SG200-54 0.687 3.023 1.099 2.097 0.278 0.636 0.734 2.838 -0.700 0.172 2.301 0.907 0.577 3.023 1.058 1.050 31.665 31.425 28.982 3372 1176
550SG200-68 0.862 3.761 1.368 2.089 0.344 0.631 1.460 3.510 -0.689 0.180 2.289 0.909 0.755 3.761 1.368 1.361 45.387 45.149 39.170 4793 1298
550SG200-97 1.219 5.229 1.901 2.072 0.471 0.622 4.201 4.816 -0.667 0.197 2.263 0.913 1.066 5.229 1.901 1.891 65.164 64.815 56.931 6657 1207
550SG250-33 0.457 2.140 0.778 2.163 0.302 0.813 0.182 2.936 -1.157 0.109 2.584 0.800 0.324 2.051 0.644 0.634 19.272 18.975 15.414 997 587
550SG250-43 0.594 2.767 1.006 2.158 0.389 0.809 0.403 3.788 -1.149 0.104 2.575 0.801 0.446 2.744 0.860 0.848 25.735 25.384 22.319 2141 952
550SG250-54 0.744 3.442 1.252 2.151 0.483 0.806 0.794 4.701 -1.141 0.098 2.565 0.802 0.576 3.442 1.092 1.078 32.686 32.274 30.488 3372 1176
550SG250-68 0.933 4.286 1.559 2.143 0.599 0.801 1.581 5.835 -1.131 0.090 2.552 0.804 0.745 4.286 1.418 1.403 42.443 42.007 41.569 4793 1298
550SG250-97 1.320 5.970 2.171 2.126 0.826 0.791 4.552 8.069 -1.108 0.073 2.525 0.807 1.168 5.970 2.133 2.121 71.321 70.907 64.998 6657 1207
550SG300-43 0.639 3.103 1.128 2.203 0.622 0.987 0.434 5.742 -1.597 0.369 2.894 0.695 0.443 2.984 0.876 0.859 26.214 25.729 23.034 2141 952
550SG300-54 0.800 3.861 1.404 2.197 0.773 0.983 0.855 7.139 -1.589 0.363 2.884 0.696 0.580 3.725 1.128 1.110 33.781 33.222 31.625 3372 1176
550SG300-68 1.004 4.812 1.750 2.189 0.960 0.978 1.702 8.883 -1.579 0.355 2.870 0.697 0.756 4.753 1.476 1.455 44.180 43.572 43.406 4793 1298
550SG300-97 1.422 6.711 2.440 2.172 1.332 0.968 4.902 12.348 -1.557 0.340 2.843 0.700 1.187 6.711 2.310 2.293 69.159 68.650 69.483 6657 1207
550SG300-118 1.724 8.048 2.927 2.161 1.590 0.960 8.837 14.766 -1.541 0.328 2.822 0.702 1.486 8.048 2.812 2.793 93.863 93.245 87.622 7956 1142
600SG162-33 0.379 1.854 0.618 2.211 0.104 0.523 0.151 1.090 -0.234 0.432 2.284 0.990 0.279 1.854 0.558 0.551 16.702 16.505 12.720 878 634
600SG162-43 0.492 2.392 0.797 2.205 0.133 0.519 0.334 1.386 -0.222 0.441 2.276 0.990 0.386 2.392 0.741 0.734 22.192 21.969 18.413 1959 1073
600SG200-33 0.440 2.291 0.764 2.282 0.187 0.653 0.176 2.203 -0.744 0.097 2.487 0.910 0.333 2.262 0.682 0.675 20.417 20.203 16.201 878 634
600SG200-43 0.572 2.962 0.987 2.276 0.241 0.650 0.388 2.837 -0.737 0.102 2.479 0.912 0.470 2.962 0.931 0.924 27.880 27.673 23.374 1959 1073
600SG200-54 0.715 3.683 1.228 2.269 0.299 0.646 0.764 3.513 -0.729 0.108 2.469 0.913 0.605 3.683 1.182 1.174 35.379 35.150 31.797 3372 1451
600SG200-68 0.898 4.586 1.529 2.261 0.370 0.642 1.521 4.350 -0.719 0.116 2.457 0.914 0.791 4.586 1.529 1.522 50.735 50.518 43.111 5350 1796
600SG200-97 1.269 6.386 2.129 2.243 0.508 0.633 4.376 5.980 -0.697 0.133 2.432 0.918 1.117 6.386 2.129 2.119 72.948 72.629 63.731 7610 1726
600SG250-33 0.475 2.599 0.866 2.340 0.320 0.822 0.189 3.590 -1.180 0.170 2.747 0.815 0.341 2.496 0.720 0.710 21.563 21.269 16.810 878 634
600SG250-43 0.617 3.362 1.121 2.334 0.413 0.818 0.418 4.633 -1.173 0.165 2.737 0.816 0.469 3.339 0.961 0.949 28.760 28.412 24.389 1959 1073
600SG250-54 0.772 4.183 1.394 2.328 0.513 0.815 0.824 5.752 -1.165 0.160 2.728 0.818 0.604 4.183 1.219 1.206 36.501 36.093 33.384 3372 1451
600SG250-68 0.969 5.213 1.738 2.320 0.636 0.810 1.642 7.145 -1.155 0.152 2.715 0.819 0.780 5.213 1.582 1.567 47.351 46.922 45.633 5350 1796
600SG250-97 1.371 7.270 2.423 2.303 0.879 0.800 4.727 9.893 -1.133 0.137 2.688 0.822 1.219 7.270 2.381 2.369 79.592 79.202 72.361 7610 1726
600SG300-43 0.662 3.761 1.254 2.384 0.655 0.995 0.449 6.972 -1.616 0.429 3.047 0.719 0.466 3.628 0.979 0.962 29.297 28.809 25.131 1959 1073
600SG300-54 0.829 4.683 1.561 2.377 0.814 0.991 0.885 8.670 -1.608 0.424 3.036 0.720 0.608 4.526 1.260 1.241 37.713 37.153 34.564 3372 1451
600SG300-68 1.040 5.840 1.947 2.369 1.012 0.986 1.763 10.793 -1.598 0.417 3.023 0.721 0.791 5.775 1.646 1.625 49.272 48.663 47.543 5350 1796
600SG300-97 1.473 8.155 2.718 2.353 1.404 0.976 5.078 15.015 -1.577 0.402 2.996 0.723 1.238 8.155 2.572 2.556 77.021 76.525 76.434 7610 1726
600SG300-118 1.786 9.789 3.263 2.341 1.678 0.969 9.154 17.967 -1.562 0.391 2.976 0.725 1.548 9.789 3.134 3.116 104.620 104.024 97.696 9118 1649
800SG162-33 0.448 3.631 0.908 2.845 0.130 0.538 0.179 2.193 -0.302 0.261 2.912 0.989 0.298 3.631 0.754 0.744 22.576 22.270 16.445 595 595
800SG162-43 0.582 4.691 1.173 2.839 0.166 0.534 0.395 2.796 -0.292 0.269 2.903 0.990 0.439 4.691 1.056 1.047 31.604 31.335 24.107 1324 1269
800SG200-33 0.509 4.453 1.113 2.957 0.230 0.672 0.203 4.278 -0.791 0.064 3.134 0.936 0.352 4.422 0.930 0.919 27.843 27.525 21.591 595 595
800SG200-43 0.662 5.765 1.441 2.951 0.296 0.669 0.449 5.516 -0.784 0.059 3.126 0.937 0.522 5.765 1.325 1.317 39.673 39.425 31.423 1324 1269
800SG200-54 0.829 7.181 1.795 2.944 0.367 0.666 0.885 6.840 -0.777 0.054 3.117 0.938 0.701 7.181 1.731 1.724 51.819 51.620 43.141 2632 1994
800SG200-68 1.040 8.960 2.240 2.935 0.455 0.662 1.763 8.484 -0.767 0.047 3.105 0.939 0.933 8.960 2.240 2.235 74.340 74.180 59.159 5301 3157
800SG200-97 1.473 12.530 3.133 2.917 0.629 0.653 5.078 11.713 -0.748 0.033 3.081 0.941 1.320 12.530 3.133 3.126 107.352 107.117 93.788 10885 4451
800SG250-33 0.544 5.002 1.250 3.033 0.382 0.838 0.217 6.837 -1.202 0.321 3.368 0.873 0.360 4.848 0.980 0.967 29.352 28.942 22.427 595 595
800SG250-43 0.707 6.478 1.620 3.027 0.493 0.835 0.479 8.833 -1.196 0.317 3.360 0.873 0.522 6.468 1.363 1.349 40.806 40.395 32.761 1324 1269
800SG250-54 0.885 8.074 2.019 3.020 0.612 0.832 0.945 10.975 -1.189 0.312 3.350 0.874 0.701 8.074 1.782 1.769 53.363 52.965 45.165 2632 1994
800SG250-68 1.111 10.081 2.520 3.012 0.761 0.827 1.883 13.649 -1.179 0.305 3.339 0.875 0.923 10.081 2.304 2.291 68.996 68.586 62.282 5301 3157
800SG250-97 1.575 14.116 3.529 2.994 1.055 0.818 5.428 18.950 -1.160 0.292 3.314 0.877 1.422 14.116 3.466 3.456 115.861 115.535 100.510 10885 4451
800SG300-43 0.752 7.192 1.798 3.092 0.767 1.010 0.510 13.119 -1.617 0.573 3.633 0.802 0.518 7.010 1.387 1.368 41.519 40.945 33.663 1324 1269
800SG300-54 0.942 8.967 2.242 3.086 0.954 1.006 1.006 16.324 -1.610 0.568 3.623 0.802 0.705 8.758 1.839 1.820 55.068 54.497 46.575 2632 1994
800SG300-68 1.183 11.202 2.800 3.078 1.187 1.002 2.004 20.337 -1.601 0.562 3.611 0.803 0.934 11.142 2.394 2.373 71.673 71.061 64.531 5301 3157
800SG300-97 1.676 15.702 3.926 3.061 1.651 0.993 5.779 28.342 -1.582 0.549 3.586 0.805 1.441 15.702 3.719 3.703 111.337 110.877 105.253 10885 4451
800SG300-118 2.034 18.902 4.725 3.048 1.976 0.986 10.426 33.962 -1.568 0.540 3.567 0.807 1.796 18.902 4.539 4.523 151.547 151.009 136.886 13768 4546

Table Notes:

1. Section properties and capacities are calculated in accordance with AISI S100-07 with 2010 supplement.
2. Tabulated gross properties are based on the full-unreduced cross section of the studs, away from punchouts.
3. Effective section properties incorporate the strength increase from the cold-work of forming as applicable per AISI S100-07 Sec. A7.2.
4. Net effective section properties are calculated at a cross section through the punchout.
5. Allowable moment is the lesser of Mal and Mad. Stud distortional buckling is based on an assumed kΦ = 0.
6. For deflection calculations, use the effective moment of inertia.
7. The effective moment of inertia for deflection is calculated at a stress which results in a section modulus such that the stress times the section modulus at that stress is equal to the allowable moment. AISI S100-07 Procedure I for serviceability determination has been used.

TSN's Product Catalogs are an essential resource for the design of cold formed steel.  Developed by Engineers, the catalogs contain design data for members connectors, and fasteners.

SigmaStud® and the rest of TSN's Load Bearing Member Products can be found in the following Catalogs:



For a full list of our product catalogs, specification sections, inspection checklists, and research reports please click here.
