StiffClip® PL
Features
- Guide holes for quick attachment to framing members
- No time and expense spent cutting steel shapes
- Utilizes certified, 50ksi steel
- Guide holes are 0.172” in diameter unless specified.
- Guide holes have ½” minimum edge distance and spacing of 1″, 1 ½” or 2″.
Order Information
StiffClip PL is made to order per project specifications. Contact TSN for pricing and order information.
| Mils | Gauge | Decimal (in) |
| 33 | 20 | 0.0346 |
| 43 | 18 | 0.0451 |
| 54 | 16 | 0.0566 |
| 68 | 14 | 0.0713 |
| 97 | 12 | 0.1017 |
| 118 | 10 | 0.1242 |
Nomenclature
StiffClip PL is available in many different shapes and is designated as width x length – material thickness.
Example: 10″ wide x 24″ long with 68 mil thickness
Designate: StiffClip® PL10x 24-68
* Clip sizes vary within each application
** StiffClip PL are typically made to order per project specifications.
*** Call TSN today for pricing and order information!
Material Composition
Catalogs
|
|
For a full list of our product catalogs, specification sections, inspection checklists, and research reports please click here.
StiffClip® PL Downloads
StiffClip® PL Applications
Installation Instructions
- Place StiffClip PL on framing member chords and/or webs as designed.
- Attach StiffClip PL to framing members with symmetrically placed required number of screws.
Allowable Loads
Allowable Loads
Plates used to connect framing are generally considered as pinned joints. Load transfers through screw or welded connections between members.
Notes:
- All guide holes may not require fasteners. Number and size of fasteners used is based on fastener manufacturer’s allowable load data, and is to be determined by designer.
- Guide holes are 0.172″ in diameter unless specified.
- Guide holes have ½” minimum edge distance and 1″ minimum spacing. Spacing will vary based on plate size and specified project requirements.
