VertiClip® SLB

This vertical deflection clip is used to connect exterior cold-formed steel curtain wall studs to the slab, bypassing the primary structure , while allowing for vertical deflection of the structure up to 2” (1” up & 1” down). TSN’s patented Step Bushing Technology® provides an anti-friction and anti-seizure connection between the clip and the stud web surface.

Features
  • ICC-ES Approved, report #ESR-2049
  • Attaches to structure with PAF or welds
  • Load-rated positive mechanical attachment at each stud
  • Patented Step Bushing Technology® provides friction-free motion for smooth vertical deflection
  • Eliminates loose friction-held assemblies, heavy deep-leg track, & top row of wall bridging/strapping
  • Load-rated #12 screws provided for vertical deflection connection to stud web
  • Manufactured with certified, 50ksi, 68 mil, G90 cold-formed steel
Order Information
Qty/Box
SLB250
150
SLB362/400
50
SLB600
50
SLB600-HD
50
SLB600-10**
25
SLB600-12**
25
SLB800
50
SLB800-10**
25
SLB800-12**
25
SLB1000
25
SLB1200
25
Lbs/Box
SLB250
20
SLB362/400
28
SLB600
38
SLB600-HD
38
SLB600-10**
30
SLB600-12**
35
SLB800
50
SLB800-10**
30
SLB800-12**
35
SLB1000
30
SLB1200
35
Qty/Skid
SLB250
2,250
SLB362/400
2,250
SLB600
2,250
SLB600-HD
2,250
SLB600-10**
1,125
SLB600-12**
1,000
SLB800
1,600
SLB800-10**
1,125
SLB800-12**
1,000
SLB1000
1,125
SLB1200
1,000
Lbs/Skid
SLB250
900
SLB362/400
1,260
SLB600
1,710
SLB600-HD
1,710
SLB600-10**
1,800
SLB600-12**
1,760
SLB800
1,600
SLB800-10**
1,800
SLB800-12**
1,760
SLB1000
1,800
SLB1200
1,400

Nomenclature:
VertiClip SLB is designated by type (SLB), followed by stud depth in inches multiplied by 100.

Example: 6″ stud
Designate: VertiClip® SLB600

* Use of strengthening ribs and return bends varies with each clip.
** The VertiClip SLB600-10, 600-12, 800-10 and 800-12 accommodate an even greater construction tolerance of studs from structure. The VertiClip SLBxxx-10 is 10″ in depth and the VertiClip SLBxxx-12 is 12″ in depth with slot spacings designed for a 6″ or 8″ stud

Material Composition
ASTM A1003/A1003M Structural Grade 50 (340) Type H, ST50H (ST340H): 50ksi (340MPa) minimum yield strength, 65ksi (450MPa) minimum tensile strength, 68mil minimum thickness (14 gauge, 0.0713” design thickness) with ASTM A653/A653M G90 (Z275) hot dipped galvanized coating.
Catalogs
TSN’s Product Catalogs are an essential resource for the design of cold formed steel. Developed by Engineers, the catalogs contain design data for members, connectors, and fasteners. VertiClip® SLB can be found in the following Catalogs:

TSN Cold-Formed Steel Framing Connections Order Catalog

TSN Connections Technical Catalog

TSN Cold-Formed Steel Framing Connections Technical Catalog

TSN Connections Order Catalog

For a full list of our product catalogs, specification sections, inspection checklists, and research reports please click here.

US Patents #5,467,566 & #5,906,080

VertiClip® SLB Downloads

VertiClip® SLB Applications

The attachment of VertiClip SLB to the primary structure may be made with a PAF, screw/bolt anchors or weld and is dependent upon the base material (steel or concrete) and the design configuration.

VertiClip_SLB_Exterior_Slab_Bypass

VertiClip SLB Exterior Slab Bypass - Attached with Screws

VertiClip_SLB_HD_Application

VertiClip SLB-HD Exterior Slab Bypass - Attached with PAF's

Installation Instructions

  1. Place VertiClip® angle against structural pour stop.
  2. Attach SLB to structure with required fasteners.
  3. Fasten SLB to stud with provided screws through Step Bushings.

VertiClip® SLB Allowable Loads

33mil (20ga), 33ksi Stud
33mil (20ga), 50ksi Stud
43mil (18ga), 33ksi Stud
43mil (18ga), 50ksi Stud
54mil (16ga), 33ksi Stud
54mil (16ga), 50ksi Stud
68mil (14ga), 50ksi Stud
97mil (12ga), 50ksi Stud
Maximum Allowable Clip Load
VertiClip® SLB - Recommended Allowable Load (lbs): F1 & F2
F1 Load Direction
SLB250 & SLB362/400

w/2 #12 screws
95
138
124
179
156
225
226
226
226
VertiClip® SLB - Recommended Allowable Load (lbs): F1 & F2
F1 Load Direction
SLB600

w/2-3 #12 screws
95
138
124
179
156
225
226
226
226
VertiClip® SLB - Recommended Allowable Load (lbs): F1 & F2
F1 Load Direction
SLB800

w/2-3 #12 screws
95
118
118
118
118
118
118
118
118
VertiClip® SLB - Recommended Allowable Load (lbs): F1 & F2
F2 Load Direction
SLB250, SLB362/400*, SLB600 & SLB800

w/2 #12 screws
376
544
560
810
788
1,138
1,434
1,434
1,600
VertiClip® SLB - Recommended Allowable Load (lbs): F1 & F2
F2 Load Direction
SLB250, SLB362/400*, SLB600 & SLB800

w/3 #12 screws
564
816
840
1,215
1,182
1,600
1,600
1,600
1,600
VertiClip® SLB - Recommended Allowable Load (lbs): F1 & F2
F2 Load Direction
SLBxxx-10, SLBxxx-12, SLB1000, & SLB1200

w/2 #12 screws
376
544
560
810
788
933
933
933
933
VertiClip® SLB - Recommended Allowable Load (lbs): F1 & F2
F2 Load Direction
SLBxxx-10, SLBxxx-12, SLB1000, & SLB1200

w/3 #12 screws
564
816
840
933
933
933
933
933
933

Notes:

  • VertiClip SLB is designed to support horizontal loads, and should not be used in axial load-bearing walls.
  • Allowable loads have not been increased for wind, seismic, or other factors.
  • Use of strengthening ribs and return bends vary with each clip.
  • #12 screws are provided with each step bushing for attachment to the stud web. Load requirements do not always justify the use of a third screw.
  • Guide holes for attachment to structure are 0.172″ diameter for SLB250, SLB362/400, SLBXXX-10, SLBXXX-12, SLB1000, and SLB1200. Guideholes are 0.141″ diameter for SLB600 and SLB800.
  • Fasten within 3/4″ of the angle heel (centerline of the 1-1/2″ leg) to minimize eccentric load transfer.
  • Total vertical deflection of up to 2″ (1″ up and 1″ down). Deflection requirements greater than 1″ (up and down) are available.
  • Allowable load tables incorporate eccentric loading of fasteners. Values with welded connection may increase.
  • Fasteners attaching clip to structure should be installed symmetrically around the center line of the clip. The allowable load of the clip may be reduced if fasteners are not installed symmetrically.
  • Three slots are standard in 6″ and higher web depths to accommodate construction tolerances. Use of a thrid screw and bushing is dependent upon load configuration. 250 and 362/400 sizes have only two slots and two screws.
  • For LRFD strengths contact TSN technical services.
VertiClip_SLB_Load_Direction

VertiClip® SLB Load Direction

VertiClip® SLB-HD Allowable Loads

33mil (20ga), 33ksi Stud
43mil (18ga), 33ksi Stud
54mil (16ga), 33ksi Stud
54mil (16ga), 50ksi Stud
68mil (14ga), 50ksi Stud
97mil (12ga), 50ksi Stud
Maximum Allowable Clip Load
VertiClip® SLB600-HD - Recommended Allowable Load (lbs): F1 & F2
F1 Allowable (ASD) Loads

w/2-3 #12 Screws
95
124
156
225
234
234
234
VertiClip® SLB600-HD - Recommended Allowable Load (lbs): F1 & F2
F2 Allowable (ASD) Loads with Two ¼” Concrete Fasteners

w/2* #12 Screws
376
560
788
1,138
1,187
1,187
1,187
VertiClip® SLB600-HD - Recommended Allowable Load (lbs): F1 & F2
F2 Allowable (ASD) Loads with Two ¼” Concrete Fasteners

w/3 #12 Screws
564
840
1,182
1,187
1,187
1,187
1,187
VertiClip® SLB600-HD - Recommended Allowable Load (lbs): F1 & F2
F2 Allowable (ASD) Loads with One ½” Concrete Anchor

w/2* #12 Screws
376
560
788
1,003
1,003
1,003
1,003
VertiClip® SLB600-HD - Recommended Allowable Load (lbs): F1 & F2
F2 Allowable (ASD) Loads with One ½” Concrete Anchor

w/3 #12 Screws
564
840
1,003
1,003
1,003
1,003
1,003

Notes:

  • VertiClip SLB600-HD is designed to support horizontal loads, and should not be used in axial load-bearing walls.
  • Allowable loads have not been increased for wind, seismic, or other factors.
  • #12 screws are provided with each step bushing for attachment to the stud web. Load requirements do not always justify the use of a third screw.
  • Guide holes for attachment to structure are 0.375″ diameter for (2) 1/4″ concrete screws, and 0.625″ diameter for (1) 1/2″ concrete anchor.
  • Fasten within 3/4″ of the angle heel (centerline of the 1-1/2″ leg) to minimize eccentric load transfer.
  • Total vertical deflection of up to 2″ (1″ up and 1″ down).
  • Loads listed reflect force in a single direction. When multiple loads act on the connection, it is the responsibility of the designer to check the interaction of the forces.
  • The recommended allowable load is for the clip and attachment to the stud only. The design professional must design the attachment to the primary structure.
  • For LRFD strengths contact TSN technical services.
VertiClip_SLB_HD_Load_Direction

VertiClip® SLB-HD Load Direction
